Features of High Definition CNC Plasma Cutter for Sheet Metal Manufacturing:

1. Welded structure of thickening square tube, together with top brand guide rail to ensure high running speed and accuracy.

2. Hyperthermal plasma power supply together with high sensitive arc pressure adjuster. Self-adjusting can choose the best distance between plasma gun and working piece automatically to ensure high accuracy cutting.

3. High definition CNC pasma cutter for sheet metal uses STARFIRE control system with FastCAM software for auto material saving function, large capacity storing function, convenient to read and process.

4. Cutting head with cooling system can quickly cool surface of material to avoid burr and residue.

5. Overall stepper motor with high precision rack and pinion, to ensure the cnc plasma cutter has small noise, smooth, precise coordinates of the mobile performance.

6. Software compatibility. Artcam

Product Specifications:

-Working area: 1500mm x 3000mm
-Working material: Iron, Steel, Aluminum sheets,
Galvanized sheets, titanium plates
-Working thickness: 0.5-30mm
-Cutting speed: 0-6000mm/min
-Power: 8.5kW
-Input Voltage: 380V 50Hz
-Plasma current, A: China huayuan power 200A
-oxyfuel head
-Connecting way: USB
-Working mode: Untouched arc striking
-Cooling mode: Water pipe and tank
-Z-axis travel: 0-70mm
-Elastic raise: 0-5mm
-Rail guide: Precision work square,high precision
-Transmit way: Taiwan imported ball screw
-Operation language: English
-Command: G code, Uoo, mmg, pit
-Optional power source: China huayuan 200A
-Spare parts: Electrode, electricity nozzle and water
– China leadshine stepper motor and driver
